Non Contact Ultrasonic Water Level Gauge Meter Ultrasonic Water Oil Fuel Level Sensor River Level
Why choose us:
1. 23 years of instrumentation equipment production experience
2. Product support OEM / ODM, export to more than 100 countries
3. The company area 20,000 square meters, and 150+ orders per month
4. Provide email, skype, whatsapp provide 24-hour one-on-one technical support service online
Related Production
Product Description
Non-contact ultrasonic level sensor for water and fuel measuring is a non-contact highly accuracy and cost-effective level measuring instrument which is easily installed and maintained. It can meet most of the material level measurement requirements without touching the medium. The instrument has the automatic temperature correction, automatic fixed distance calibration and other calibration functions to make the measurement results more accurate and reliable.
Product Parameters
function | all in one |
measuring distance | 5m,10m,15m,20m,30m,40m,50m,60m |
| accuracy | 0.5%-1.0% |
show | Chinese LCD |
analog output | 4~20mA/510Ω 4~20mA/250Ω |
relay output | AC 250V/8A DC 30V/5A |
power supply | 24VDC 220V AC+15% 50Hz |
environment temperature | display instrument: -20~60ºC |
communication | 485or 232 |
protection class | display instrument: IP66 |
probe cable | no |
Detailed Images
Product Application
If you have any questions, please send us inquiry and contact us directly, we will provide you with professional help.
